* Up to 2.488Gb/s bi-directional data links
* 1310nm DFB laser and PIN photodetector for 20km transmission
The SFP transceivers are high performance, cost effective modules supporting dual data-rate of 2.488Gbps and 20km transmission distance with SMF.
The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
* Compliant with SFP MSA and SFF-8472 with Duplex LC receptacle
* Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
* Compatible with RoHS
* +3.3V single power supply
* Operating case temperature:
Standard : 0 to +70°C
Extended : -20 to +85°C
* SDH STM-16 and SONET OC-48 system
* 2X Fiber Channel
* Switch to Switch interface
* Switched backplane applications
* Router/Server interface
* Other optical transmission systems
1 – Absolute Maximum Ratings
Parameter
Symbol
Min
Max
Unit
Supply Voltage
Vcc
-0.5
4.5
V
Storage Temperature
Ts
-40
+85
°C
Operating Humidity
–
5
85
%
2 – Recommended Operating Conditions
Typical
Operating Case Temperature
Standard
Tc
0
+70
Extended
-20
Power Supply Voltage
3.13
3.3
3.47
Power Supply Current
Icc
300
mA
Data Rate
2.488
Gbps
Notes
Transmitter
Centre Wavelength
λc
1260
1310
1360
nm
Spectral Width (-20dB)
σ
1
Side Mode Suppression Ratio
SMSR
30
dB
Average Output Power
Pout
-5
dBm
Extinction Ratio
ER
9
Optical Rise/Fall Time (20%~80%)
tr/tf
0.16
ns
Data Input Swing Differential
VIN
400
1800
mV
2
Input Differential Impedance
ZIN
90
100
110
Ω
TX Disable
Disable
2.0
Enable
0.8
TX Fault
Fault
Normal
Receiver
1580
Receiver Sensitivity
-18
3
Receiver Overload
-3
LOS De-Assert
LOSD
LOS Assert
LOSA
-30
LOS Hysteresis
4
Data Output Swing Differential
Vout
370
LOS
High
Low
